Resin Bonded Cartridge Filters

Product Description

Trinity Pure-BONDRes in bonded cartridge filters feature an advanced manufacturing process that produces a rigid graded density structure that allows the filter to withstand extreme viscosity and temperatures without deformation or collapse. The true graded density configuration allows complete utilization of the filter depth, with larger particles captured in the outer zone and finer particles trapped in the inner qualifying zone. The grooved design increases the surface area of the filter hence reducing the clean differential pressure and increasing the dirt holding capacity of the filter. The rigid construction ensures consistency, reproducible performance free from bye-pass and unloading.

Features& Benefits:

• Grooved outer surface increases surface area for extended service life
• Rigid structure designed to handle high differential pressure and can be used for high viscosity applications
• High voids volume ensures better dirt holding capacity resulting in longer service life
• Available in a wide range of removal ratings from0.2 to 150 micron
• Two different types of Fibers & Resins (Acrylic Phenolic& Cellulose Melamine) for use in Industrial and pharmaceuticals/ Food &Beverages Applications respectively.
• No Metal/ plastic cores for easy disposal
• Broad chemical compatibility

Specification

Code

Fiber material

Resin

Appearance

Removal rating

Application

AP

Acrylic

Phenolic

Brown

1 to 125 micron

Industrial

CM

Cellulose

Melamine

White

0.2 to 50 micron

Pharma/ F&B
